The Offshore 41 cheoy lee is a 40.92ft masthead sloop designed by Ray Richards and built in fiberglass by Cheoy Lee Shipyard since 1972.
100 units have been built.
The Offshore 41 cheoy lee is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Offshore 41 cheoy lee | ||
| Length | 40.92 ft | ||
| Beam | 12.75 ft | ||
| Draft | 6 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.90 | ||
| Ballast / displ. | 42.18 % | ||
| Displ. / length | 274.40 | ||
| Comfort ratio | 31.38 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 32.50 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 21100 lbs | ||
| Ballast | 8900 lbs | ||
| Hull speed | 7.64 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 756 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 442.88 sq.ft | ||
| Sail area main | 312.80 sq.ft | ||
| I | 51.20 ft | ||
| J | 17.30 ft | ||
| P | 46 ft | ||
| E | 13.60 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 130 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | Ray Richards | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 100 |
