The Pcc kettenburg is a 46.33ft fractional sloop designed by George W. Kettenburg Jr. and built in wood by Kettenburg Boats between 1949 and 1958.
24 units have been built.
The Pcc kettenburg is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat.
Main features
| Model | Pcc kettenburg | ||
| Length | 46.33 ft | ||
| Beam | 9.50 ft | ||
| Draft | 6.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.46 | ||
| Ballast / displ. | 35 % | ||
| Displ. / length | 272.48 | ||
| Comfort ratio | 42.45 | ||
| Capsize | 1.40 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Wood | ||
| Waterline length | 32 ft | ||
| Maximum draft | 6.42 ft | ||
| Displacement | 20000 lbs | ||
| Ballast | 7000 lbs | ||
| Hull speed | 7.58 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 801 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 328.80 sq.ft | ||
| Sail area main | 471.98 sq.ft | ||
| I | 41.10 ft | ||
| J | 16 ft | ||
| P | 46.50 ft | ||
| E | 20.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Kettenburg Boats | ||
| Designer | George W. Kettenburg Jr. | ||
| First built | 1949 | ||
| Last built | 1958 | ||
| Number built | 24 |
