The Pearson 10m is a 33.04ft masthead sloop designed by William Shaw and built in fiberglass by Pearson Yachts between 1973 and 1981.
230 units have been built.
The Pearson 10m is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Pearson 10m | ||
| Length | 33.04 ft | ||
| Beam | 11 ft | ||
| Draft | 5.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.67 | ||
| Ballast / displ. | 43.77 % | ||
| Displ. / length | 244.27 | ||
| Comfort ratio | 26.52 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 28.33 ft | ||
| Maximum draft | 5.92 ft | ||
| Displacement | 12441 lbs | ||
| Ballast | 5445 lbs | ||
| Hull speed | 7.13 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 524 sq.ft | ||
| Air draft | 48 ft | ||
| Sail area fore | 312.40 sq.ft | ||
| Sail area main | 211.75 sq.ft | ||
| I | 44 ft | ||
| J | 14.20 ft | ||
| P | 38.50 ft | ||
| E | 11 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pearson Yachts | ||
| Designer | William Shaw | ||
| First built | 1973 | ||
| Last built | 1981 | ||
| Number built | 230 |
