The Pearson 22 is a 22.25ft fractional sloop designed by William H. Shaw and built in fiberglass by Pearson Yachts between 1968 and 1972.
The Pearson 22 is a light sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Pearson 22 | ||
| Length | 22.25 ft | ||
| Beam | 7.75 ft | ||
| Draft | 3.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.49 | ||
| Ballast / displ. | 38.46 % | ||
| Displ. / length | 183.32 | ||
| Comfort ratio | 13.38 | ||
| Capsize | 2.26 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 18.50 ft | ||
| Maximum draft | 3.42 ft | ||
| Displacement | 2600 lbs | ||
| Ballast | 1000 lbs | ||
| Hull speed | 5.76 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 218 sq.ft | ||
| Air draft | 29.75 ft | ||
| Sail area fore | 111.32 sq.ft | ||
| Sail area main | 106.95 sq.ft | ||
| I | 24.20 ft | ||
| J | 9.20 ft | ||
| P | 23 ft | ||
| E | 9.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pearson Yachts | ||
| Designer | William H. Shaw | ||
| First built | 1968 | ||
| Last built | 1972 | ||
| Number built | 0 | ?? |
