The Piana 30 is a 29.5ft frac. sloop (rotating spar) designed by Bertrand. Desray and built in plywood and epoxy by Naval Force 3 (FRA) since 1991.
It accomodates 4 people in 2 cabins plus salon.
The Piana 30 is an ultralight sailboat which is a very high performer. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Piana 30 | ||
| Length | 29.50 ft | ||
| Beam | 16.33 ft | ||
| Draft | 2.33 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 30.14 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 83.10 | ||
| Comfort ratio | 5.84 | ||
| Capsize | 3.94 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Plywood and epoxy | ||
| Waterline length | 29 ft | ||
| Maximum draft | 2.33 ft | ||
| Displacement | 4540 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.22 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Frac. Sloop (Rotating Spar) | ||
| Sail area (100%) | 515 sq.ft | ||
| Air draft | 44.33 ft | ||
| Sail area fore | 237 sq.ft | ||
| Sail area main | 301 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 13 gals |
Accommodations
| Water capacity | 53 gals | ||
| Headroom | 5.74 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 4 | ||
| Nb heads | 1 |
Builder data
| Builder | Naval Force 3 (FRA) | ||
| Designer | Bertrand. Desray | ||
| First built | 1991 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
