The Puma 27 is a 26.08ft masthead sloop designed by Ron Holland and built in fiberglass by Puma Yachts (Nao-Glass)(ESP) since 1979.
The Puma 27 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Puma 27 | ||
| Length | 26.08 ft | ||
| Beam | 9.19 ft | ||
| Draft | 4.82 ft | ||
| Country | Spain (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.06 | ||
| Ballast / displ. | 40.74 % | ||
| Displ. / length | 243.87 | ||
| Comfort ratio | 19.21 | ||
| Capsize | 2.09 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.55 ft | ||
| Maximum draft | 4.82 ft | ||
| Displacement | 5467 lbs | ||
| Ballast | 2227 lbs | ||
| Hull speed | 6.22 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 330 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 192.33 sq.ft | ||
| Sail area main | 137.32 sq.ft | ||
| I | 33.98 ft | ||
| J | 11.32 ft | ||
| P | 28.97 ft | ||
| E | 9.48 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 26 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Puma Yachts (Nao-Glass)(ESP) | ||
| Designer | Ron Holland | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
