The Quanta 28 is a 28.42ft masthead sloop designed by Ray Wall and built in fiberglass by Quanta Yachts Ltd. (CAN) between 1985 and 1988.
12 units have been built.
The Quanta 28 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Quanta 28 | ||
| Length | 28.42 ft | ||
| Beam | 9.75 ft | ||
| Draft | 5.50 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.07 | ||
| Ballast / displ. | 44.64 % | ||
| Displ. / length | 267.56 | ||
| Comfort ratio | 21.10 | ||
| Capsize | 2.05 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 22.58 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 6900 lbs | ||
| Ballast | 3080 lbs | ||
| Hull speed | 6.37 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 408 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 229.13 sq.ft | ||
| Sail area main | 181.41 sq.ft | ||
| I | 39 ft | ||
| J | 11.75 ft | ||
| P | 33.75 ft | ||
| E | 10.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Quanta Yachts Ltd. (CAN) | ||
| Designer | Ray Wall | ||
| First built | 1985 | ||
| Last built | 1988 | ||
| Number built | 12 |
Other photos
