The Ranger 20 is a 20.0ft fractional sloop designed by Raymond Richards and built in fiberglass by Ranger Yachts (USA) since 1972.
600 units have been built.
The Ranger 20 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Ranger 20 | ||
| Length | 20 ft | ||
| Beam | 7.87 ft | ||
| Draft | 1.87 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.33 | ||
| Ballast / displ. | 36.67 % | ||
| Displ. / length | 163.49 | ||
| Comfort ratio | 8.63 | ||
| Capsize | 2.75 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 16 ft | ||
| Maximum draft | 3.08 ft | ||
| Displacement | 1500 lbs | ||
| Ballast | 550 lbs | ||
| Hull speed | 5.36 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 191 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 102.34 sq.ft | ||
| Sail area main | 90 sq.ft | ||
| I | 23.58 ft | ||
| J | 8.68 ft | ||
| P | 22.50 ft | ||
| E | 8 ft |
Engine
| Nb engines | 0 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Ranger Yachts (USA) | ||
| Designer | Raymond Richards | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 600 |
