The Redline 25 cc is a 24.58ft masthead sloop designed by Cuthbertson & Cassian and built in fiberglass by C&C Yachts since 1969.
The Redline 25 cc is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Redline 25 cc | ||
| Length | 24.58 ft | ||
| Beam | 8 ft | ||
| Draft | 2.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.75 | ||
| Ballast / displ. | 46.51 % | ||
| Displ. / length | 213.24 | ||
| Comfort ratio | 18.34 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 20.50 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 4115 lbs | ||
| Ballast | 1914 lbs | ||
| Hull speed | 6.07 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 252 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 144.20 sq.ft | ||
| Sail area main | 108 sq.ft | ||
| I | 28 ft | ||
| J | 10.30 ft | ||
| P | 24 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | C&C Yachts | ||
| Designer | Cuthbertson & Cassian | ||
| First built | 1969 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
