The Renegade 27 Pearson is a 27.17ft masthead sloop designed by William Shaw and built in fiberglass by Pearson Yachts between 1967 and 1969.
173 units have been built.
It accomodates 4 people in 1 cabins plus salon.
The Renegade 27 Pearson is a heavy sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Renegade 27 Pearson | ||
| Length | 27.17 ft | ||
| Beam | 8.58 ft | ||
| Draft | 4.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
The Renegade 27 page from the Pearson Yachts portal
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.67 | ||
| Ballast / displ. | 32.31 % | ||
| Displ. / length | 313.33 | ||
| Comfort ratio | 25.09 | ||
| Capsize | 1.84 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 6500 lbs | ||
| Ballast | 2100 lbs | ||
| Hull speed | 6.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 340 sq.ft | ||
| Air draft | 37 ft | ||
| Sail area fore | 167.86 sq.ft | ||
| Sail area main | 172.62 sq.ft | ||
| I | 32.50 ft | ||
| J | 10.33 ft | ||
| P | 28 ft | ||
| E | 12.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 9.50 HP | ||
| Fuel capacity | 16 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 1 | ||
| Nb of berths | 4 | ||
| Nb heads | 1 |
Builder data
| Builder | Pearson Yachts | ||
| Designer | William Shaw | ||
| First built | 1967 | ||
| Last built | 1969 | ||
| Number built | 173 |
