The S2 80 c is a 26.0ft masthead sloop designed by Arthur Edmunds and built in fiberglass by S2 Yachts (USA) since 1975.
210 units have been built.
The S2 80 c is a moderate weight sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | S2 80 c | ||
| Length | 26 ft | ||
| Beam | 8 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Find boats for sale with Sailboatlab Market Analyst
Ratios
| Sail area / displ. | 15.61 | ||
| Ballast / displ. | 34.62 % | ||
| Displ. / length | 236.21 | ||
| Comfort ratio | 22.09 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.42 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 5200 lbs | ||
| Ballast | 1800 lbs | ||
| Hull speed | 6.20 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 292 sq.ft | ||
| Air draft | 35.50 ft | ||
| Sail area fore | 174.23 sq.ft | ||
| Sail area main | 117.45 sq.ft | ||
| I | 30.30 ft | ||
| J | 11.50 ft | ||
| P | 26.10 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | S2 Yachts (USA) | ||
| Designer | Arthur Edmunds | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 210 |
