The Sabre 22 scott is a 21.65ft fractional sloop designed by Alan Scott and built in fiberglass since 1981.
The Sabre 22 scott is a light sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. There is a very short water supply range.
Main features
| Model | Sabre 22 scott | ||
| Length | 21.65 ft | ||
| Beam | 8.16 ft | ||
| Draft | 1.16 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.35 | ||
| Ballast / displ. | 32.40 % | ||
| Displ. / length | 149.96 | ||
| Comfort ratio | 11.02 | ||
| Capsize | 2.47 |
Hull
| Hull type | Monohull swing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 19.03 ft | ||
| Maximum draft | 3 ft | ||
| Displacement | 2315 lbs | ||
| Ballast | 750 lbs | ||
| Hull speed | 5.85 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 233 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 7.50 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Alan Scott | ||
| First built | 1981 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
