The Sadler 26 is a 25.75ft masthead sloop designed by David Sadler and built in fiberglass by Sadler Yachts since 1981.
200 units have been built.
The Sadler 26 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Sadler 26 | ||
| Length | 25.75 ft | ||
| Beam | 9.42 ft | ||
| Draft | 4.67 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.39 | ||
| Ballast / displ. | 41.67 % | ||
| Displ. / length | 248.73 | ||
| Comfort ratio | 16.94 | ||
| Capsize | 2.24 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.50 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 4800 lbs | ||
| Ballast | 2000 lbs | ||
| Hull speed | 6.07 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 273 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 161.20 sq.ft | ||
| Sail area main | 111.82 sq.ft | ||
| I | 31 ft | ||
| J | 10.40 ft | ||
| P | 26.31 ft | ||
| E | 8.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Sadler Yachts | ||
| Designer | David Sadler | ||
| First built | 1981 | ||
| Last built | 0 | ?? | |
| Number built | 200 |
