The San juan 24 is a 24.0ft masthead sloop designed by Bruce Kirby and built in fiberglass by Clark Boat Company since 1973.
1200 units have been built.
The San juan 24 is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | San juan 24 | ||
| Length | 24 ft | ||
| Beam | 8 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.17 | ||
| Ballast / displ. | 51.56 % | ||
| Displ. / length | 192.66 | ||
| Comfort ratio | 14.86 | ||
| Capsize | 2.17 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.50 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 3200 lbs | ||
| Ballast | 1650 lbs | ||
| Hull speed | 5.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 246 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 142.50 sq.ft | ||
| Sail area main | 104 sq.ft | ||
| I | 30 ft | ||
| J | 9.50 ft | ||
| P | 26 ft | ||
| E | 8 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Clark Boat Company | ||
| Designer | Bruce Kirby | ||
| First built | 1973 | ||
| Last built | 0 | ?? | |
| Number built | 1200 |
