The Sandpiper 565 is a 18.5ft fractional sloop designed by Leonardo da Costa Sayago and built in fiberglass by C&L Boatworks since 1972.
1500 units have been built.
The Sandpiper 565 is a light sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Sandpiper 565 | ||
| Length | 18.50 ft | ||
| Beam | 7.08 ft | ||
| Draft | 0.83 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.86 | ||
| Ballast / displ. | 25 % | ||
| Displ. / length | 158.73 | ||
| Comfort ratio | 8.52 | ||
| Capsize | 2.67 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Fiberglass | ||
| Waterline length | 15 ft | ||
| Maximum draft | 2.90 ft | ||
| Displacement | 1200 lbs | ||
| Ballast | 300 lbs | ||
| Hull speed | 5.19 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 154 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 82.25 sq.ft | ||
| Sail area main | 72 sq.ft | ||
| I | 23.50 ft | ||
| J | 7 ft | ||
| P | 18 ft | ||
| E | 8 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | C&L Boatworks | ||
| Designer | Leonardo da Costa Sayago | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 1500 |
