The Santana 39 is a 39.0ft masthead sloop designed by Gary Mull / Shad Turner and built in fiberglass by Schock W.D. between 1972 and 1979.
20 units have been built.
The Santana 39 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Santana 39 | ||
| Length | 39 ft | ||
| Beam | 11.67 ft | ||
| Draft | 5.58 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Find boats for sale with Sailboatlab Market Analyst
Ratios
| Sail area / displ. | 16.04 | ||
| Ballast / displ. | 36.67 % | ||
| Displ. / length | 269.74 | ||
| Comfort ratio | 31.58 | ||
| Capsize | 1.78 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 31 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 18000 lbs | ||
| Ballast | 6600 lbs | ||
| Hull speed | 7.46 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 686 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 400 sq.ft | ||
| Sail area main | 286 sq.ft | ||
| I | 50 ft | ||
| J | 16 ft | ||
| P | 44 ft | ||
| E | 13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 38 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Schock W.D. | ||
| Designer | Gary Mull / Shad Turner | ||
| First built | 1972 | ||
| Last built | 1979 | ||
| Number built | 20 |
