The Southern cross 28 is a 30.42ft cutter designed by Thomas Gillmer and built in fiberglass by C. E. Ryder since 1978.
The Southern cross 28 is a very heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Southern cross 28 | ||
| Length | 30.42 ft | ||
| Beam | 8.50 ft | ||
| Draft | 4.67 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.99 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 462.44 | ||
| Comfort ratio | 32.66 | ||
| Capsize | 1.67 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 20.17 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 8500 lbs | ||
| Ballast | 3400 lbs | ||
| Hull speed | 6.02 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 415 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 198 sq.ft | ||
| Sail area main | 164.50 sq.ft | ||
| I | 33 ft | ||
| J | 12 ft | ||
| P | 28 ft | ||
| E | 11.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 11 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 47 gals | ||
| Headroom | 6.17 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | C. E. Ryder | ||
| Designer | Thomas Gillmer | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
