The Stevens 47 is a 46.83ft cutter designed by Sparkman & Stephens and built in fiberglass by Queen Long Marine between 1981 and 1986.
56 units have been built.
The Stevens 47 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Stevens 47 | ||
| Length | 46.83 ft | ||
| Beam | 14.25 ft | ||
| Draft | 6 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.77 | ||
| Ballast / displ. | 45.31 % | ||
| Displ. / length | 265.55 | ||
| Comfort ratio | 35.52 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 37.75 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 32000 lbs | ||
| Ballast | 14500 lbs | ||
| Hull speed | 8.23 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1052 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 570 sq.ft | ||
| Sail area main | 481.50 sq.ft | ||
| I | 60 ft | ||
| J | 19 ft | ||
| P | 53.50 ft | ||
| E | 18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 100 gals |
Accommodations
| Water capacity | 250 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Queen Long Marine | ||
| Designer | Sparkman & Stephens | ||
| First built | 1981 | ||
| Last built | 1986 | ||
| Number built | 56 |
