The Bluejacket 23 ms is a 24.25ft masthead sloop designed by William Garden and built in fiberglass by Halman Manufacturing Co. since 1984.
The Bluejacket 23 ms is a moderate weight sailboat which is under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Bluejacket 23 ms | ||
| Length | 24.25 ft | ||
| Beam | 10 ft | ||
| Draft | 2.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 10.45 | ||
| Ballast / displ. | 11.67 % | ||
| Displ. / length | 299.81 | ||
| Comfort ratio | 19.81 | ||
| Capsize | 2.20 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 20.75 ft | ||
| Maximum draft | 2.25 ft | ||
| Displacement | 6000 lbs | ||
| Ballast | 700 lbs | ||
| Hull speed | 6.10 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 215 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 24 gals |
Accommodations
| Water capacity | 15 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Halman Manufacturing Co. | ||
| Designer | William Garden | ||
| First built | 1984 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
