The Stone horse 26 is a 28.25ft cutter designed by S. S. Crocker 1931 and built in fiberglass by Edey & Duff (USA) since 1931.
150 units have been built.
The Stone horse 26 is a heavy sailboat which is a good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Stone horse 26 | ||
| Length | 28.25 ft | ||
| Beam | 7.08 ft | ||
| Draft | 3.58 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.99 | ||
| Ballast / displ. | 44.54 % | ||
| Displ. / length | 325.47 | ||
| Comfort ratio | 24 | ||
| Capsize | 1.72 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 18.33 ft | ||
| Maximum draft | 3.58 ft | ||
| Displacement | 4490 lbs | ||
| Ballast | 2000 lbs | ||
| Hull speed | 5.74 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 339 sq.ft | ||
| Air draft | 32.33 ft | ||
| Sail area fore | 149.63 sq.ft | ||
| Sail area main | 165.19 sq.ft | ||
| I | 28.50 ft | ||
| J | 10.50 ft | ||
| P | 25.75 ft | ||
| E | 12.83 ft |
Engine
| Nb engines | 1 | ||
| Total power | 6 HP | ||
| Fuel capacity | 5 gals |
Accommodations
| Water capacity | 12 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Edey & Duff (USA) | ||
| Designer | S. S. Crocker 1931 | ||
| First built | 1931 | ||
| Last built | 0 | ?? | |
| Number built | 150 |
