The Stuart 37 is a 37.0ft masthead sloop designed by Alex Stuart and built in fiberglass since 1978.
The Stuart 37 is a light sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Stuart 37 | ||
| Length | 37 ft | ||
| Beam | 11.50 ft | ||
| Draft | 6.50 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.08 | ||
| Ballast / displ. | 52.22 % | ||
| Displ. / length | 199.96 | ||
| Comfort ratio | 25.23 | ||
| Capsize | 1.91 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 31.50 ft | ||
| Maximum draft | 0 ft | ?? | |
| Displacement | 14000 lbs | ||
| Ballast | 7311 lbs | ||
| Hull speed | 7.52 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 654 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 400 sq.ft | ||
| Sail area main | 253.68 sq.ft | ||
| I | 50 ft | ||
| J | 16 ft | ||
| P | 43.55 ft | ||
| E | 11.65 ft |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 50 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Alex Stuart | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
