The Super maramu Amel is a 52.49ft masthead ketch designed by Henry Amel & J. Carteau and built in fiberglass by Amel between 1989 and 1998.
237 units have been built.
It accomodates 7 people in 2 cabins plus salon.
The Super maramu Amel is a moderate weight sailboat which is a good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Super maramu Amel | ||
| Length | 52.49 ft | ||
| Beam | 15.09 ft | ||
| Draft | 6.73 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 200000 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.45 | ||
| Ballast / displ. | 34.37 % | ||
| Displ. / length | 222.89 | ||
| Comfort ratio | 32.86 | ||
| Capsize | 1.84 |
Hull
| Hull type | Monohull wing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 41.34 ft | ||
| Maximum draft | 6.73 ft | ||
| Displacement | 35274 lbs | ||
| Ballast | 12125 lbs | ||
| Hull speed | 8.62 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 1302 sq.ft | ||
| Air draft | 68.90 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 377 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 80 HP | ||
| Fuel capacity | 158 gals |
Accommodations
| Water capacity | 264 gals | ||
| Headroom | 6.56 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 7 | ||
| Nb heads | 2 |
Builder data
| Builder | Amel | ||
| Designer | Henry Amel & J. Carteau | ||
| First built | 1989 | ||
| Last built | 1998 | ||
| Number built | 237 |
