The Swan 115 is a 115.49ft masthead sloop designed by German Frers and built in carbon fiber or composite by Nautor (Swan sailboats) since 2013.
4 units have been built.
It accomodates 15 people in 4 cabins plus salon.
The Swan 115 is an ultralight sailboat which is a very high performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser.
Main features
| Model | Swan 115 | ||
| Length | 115.49 ft | ||
| Beam | 26.64 ft | ||
| Draft | 15.42 ft | ||
| Country | Finland (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 29.59 | ||
| Ballast / displ. | 34.58 % | ||
| Displ. / length | 72.82 | ||
| Comfort ratio | 36.23 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with bulb and dual rudders | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 107.74 ft | ||
| Maximum draft | 15.42 ft | ||
| Displacement | 203971.44 lbs | ||
| Ballast | 70525.79 lbs | ||
| Hull speed | 13.91 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 6375.03 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 3191.50 sq.ft | ||
| Sail area main | 3183.85 sq.ft | ||
| I | 145.73 ft | ?? | |
| J | 43.80 ft | ||
| P | 142.72 ft | ?? | |
| E | 44.62 ft |
Engine
| Nb engines | 1 | ||
| Total power | 450 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 4 | ||
| Nb of berths | 15 | ||
| Nb heads | 7 | ?? |
Builder data
| Builder | Nautor (Swan sailboats) | ||
| Designer | German Frers | ||
| First built | 2013 | ||
| Last built | 0 | ?? | |
| Number built | 4 |
