The Swan 90 fd is a 88.91ft masthead sloop designed by German Frers and built in carbon fiber or composite by Nautor (Swan sailboats) since 2007.
12 units have been built.
The Swan 90 fd is a light sailboat which is a very high performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Swan 90 fd | ||
| Length | 88.91 ft | ||
| Beam | 21.19 ft | ||
| Draft | 9.84 ft | ||
| Country | Finland (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 27.07 | ||
| Ballast / displ. | 31.15 % | ||
| Displ. / length | 111.09 | ||
| Comfort ratio | 41.49 | ||
| Capsize | 1.68 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 80.54 ft | ||
| Maximum draft | 14.44 ft | ||
| Displacement | 130000 lbs | ||
| Ballast | 40500 lbs | ||
| Hull speed | 12.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 4319 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 2130.88 sq.ft | ||
| Sail area main | 2187.89 sq.ft | ||
| I | 120.73 ft | ?? | |
| J | 35.30 ft | ||
| P | 116.47 ft | ?? | |
| E | 37.57 ft |
Engine
| Nb engines | 1 | ||
| Total power | 285 HP | ||
| Fuel capacity | 430 gals |
Accommodations
| Water capacity | 264 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Nautor (Swan sailboats) | ||
| Designer | German Frers | ||
| First built | 2007 | ||
| Last built | 0 | ?? | |
| Number built | 12 |
