The Tanzer 85 is a 27.92ft masthead sloop designed by Johann Tanzer and built in fiberglass by Tanzer Industries Ltd. since 1978.
The Tanzer 85 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Tanzer 85 | ||
| Length | 27.92 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.33 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.33 | ||
| Ballast / displ. | 40.54 % | ||
| Displ. / length | 246.60 | ||
| Comfort ratio | 22.80 | ||
| Capsize | 1.95 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.75 ft | ||
| Maximum draft | 4.33 ft | ||
| Displacement | 7400 lbs | ||
| Ballast | 3000 lbs | ||
| Hull speed | 6.53 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 339 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 205.90 sq.ft | ||
| Sail area main | 132.75 sq.ft | ||
| I | 35.50 ft | ||
| J | 11.60 ft | ||
| P | 29.50 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 15 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tanzer Industries Ltd. | ||
| Designer | Johann Tanzer | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
