The Tartan 27 2 is a 27.0ft masthead yawl designed by Sparkman & Stephens and built in fiberglass by Tartan Marine between 1976 and 1979.
64 units have been built.
The Tartan 27 2 is a heavy sailboat which is a reasonably good performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Tartan 27 2 | ||
| Length | 27 ft | ||
| Beam | 8.63 ft | ||
| Draft | 3.17 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.46 | ||
| Ballast / displ. | 32.43 % | ||
| Displ. / length | 336.14 | ||
| Comfort ratio | 28.05 | ||
| Capsize | 1.77 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 21.42 ft | ||
| Maximum draft | 6.33 ft | ||
| Displacement | 7400 lbs | ||
| Ballast | 2400 lbs | ||
| Hull speed | 6.20 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Yawl | ||
| Sail area (100%) | 413 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 170.30 sq.ft | ||
| Sail area main | 205.88 sq.ft | ||
| I | 34.65 ft | ||
| J | 9.83 ft | ||
| P | 30.50 ft | ||
| E | 13.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tartan Marine | ||
| Designer | Sparkman & Stephens | ||
| First built | 1976 | ||
| Last built | 1979 | ||
| Number built | 64 |
Other photos
