The Tartan 34 2 is a 34.42ft masthead sloop designed by Sparkman & Stephens and built in fiberglass by Tartan Marine between 1984 and 1989.
110 units have been built.
The Tartan 34 2 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Tartan 34 2 | ||
| Length | 34.42 ft | ||
| Beam | 10.96 ft | ||
| Draft | 6.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.46 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 204.93 | ||
| Comfort ratio | 22.97 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 28.83 ft | ||
| Maximum draft | 6.25 ft | ||
| Displacement | 11000 lbs | ||
| Ballast | 4400 lbs | ||
| Hull speed | 7.19 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 538 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 304.64 sq.ft | ||
| Sail area main | 233.24 sq.ft | ||
| I | 44.80 ft | ||
| J | 13.60 ft | ||
| P | 39.20 ft | ||
| E | 11.90 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 23 gals |
Accommodations
| Water capacity | 57 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tartan Marine | ||
| Designer | Sparkman & Stephens | ||
| First built | 1984 | ||
| Last built | 1989 | ||
| Number built | 110 |
