The Trident 80 is a 26.25ft fractional sloop designed by D. Tortarolo and built in fiberglass between 1975 and 1981.
600 units have been built.
The Trident 80 is a light sailboat which is a high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Trident 80 | ||
| Length | 26.25 ft | ||
| Beam | 9.58 ft | ||
| Draft | 5.25 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.33 | ||
| Ballast / displ. | 40.42 % | ||
| Displ. / length | 180.02 | ||
| Comfort ratio | 16.26 | ||
| Capsize | 2.22 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 23.42 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 5180 lbs | ||
| Ballast | 2094 lbs | ||
| Hull speed | 6.48 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 398 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | D. Tortarolo | ||
| First built | 1975 | ||
| Last built | 1981 | ||
| Number built | 600 |
