The Valiant 40 200 235 is a 39.92ft cutter designed by Bob Perry and built in fiberglass by Uniflite Inc. (USA) between 1978 and 1980.
35 units have been built.
The Valiant 40 200 235 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Valiant 40 200 235 | ||
| Length | 39.92 ft | ||
| Beam | 12.33 ft | ||
| Draft | 6 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.09 | ||
| Ballast / displ. | 35.71 % | ||
| Displ. / length | 267.15 | ||
| Comfort ratio | 35.81 | ||
| Capsize | 1.72 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 34 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 23520 lbs | ||
| Ballast | 8400 lbs | ||
| Hull speed | 7.81 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 771 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 465.28 sq.ft | ||
| Sail area main | 306 sq.ft | ||
| I | 50.30 ft | ||
| J | 18.50 ft | ||
| P | 45 ft | ||
| E | 13.60 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 85 gals |
Accommodations
| Water capacity | 130 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Uniflite Inc. (USA) | ||
| Designer | Bob Perry | ||
| First built | 1978 | ||
| Last built | 1980 | ||
| Number built | 35 |
