The Vindo 45 is a 33.67ft masthead sloop designed by John H. Lindblom and built in fiberglass by Vindo (Nötesund Varv AB) between 1981 and 1989.
The Vindo 45 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Vindo 45 | ||
| Length | 33.67 ft | ||
| Beam | 10.83 ft | ||
| Draft | 5.17 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.20 | ||
| Ballast / displ. | 42.38 % | ||
| Displ. / length | 303.20 | ||
| Comfort ratio | 29.19 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 26.75 ft | ||
| Maximum draft | 5.17 ft | ||
| Displacement | 13000 lbs | ||
| Ballast | 5510 lbs | ||
| Hull speed | 6.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 489 sq.ft | ||
| Air draft | 46.67 ft | ||
| Sail area fore | 273.28 sq.ft | ||
| Sail area main | 223.25 sq.ft | ||
| I | 42.70 ft | ||
| J | 12.80 ft | ||
| P | 36.90 ft | ||
| E | 12.10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 25 gals |
Accommodations
| Water capacity | 70 gals | ||
| Headroom | 6.25 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Vindo (Nötesund Varv AB) | ||
| Designer | John H. Lindblom | ||
| First built | 1981 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
