The Vivacity 24 is a 23.5ft masthead sloop designed by Alan Hill and built in fiberglass by Russell Marine Ltd. since 1969.
The Vivacity 24 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a day-boat. There is a very short water supply range.
Main features
| Model | Vivacity 24 | ||
| Length | 23.50 ft | ||
| Beam | 8 ft | ||
| Draft | 3.67 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.72 | ||
| Ballast / displ. | 41.67 % | ||
| Displ. / length | 209.87 | ||
| Comfort ratio | 18.85 | ||
| Capsize | 1.99 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 20.75 ft | ||
| Maximum draft | 3.67 ft | ||
| Displacement | 4200 lbs | ||
| Ballast | 1750 lbs | ||
| Hull speed | 6.10 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 255 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 119.40 sq.ft | ||
| Sail area main | 105.53 sq.ft | ||
| I | 24 ft | ||
| J | 9.95 ft | ||
| P | 21 ft | ||
| E | 10.05 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Russell Marine Ltd. | ||
| Designer | Alan Hill | ||
| First built | 1969 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
