The Ross 930 is a 30.5ft fractional sloop designed by Murray Ross and built in fiberglass since 1982.
65 units have been built.
The Ross 930 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Ross 930 | ||
| Length | 30.50 ft | ||
| Beam | 9.25 ft | ||
| Draft | 5.50 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.55 | ||
| Ballast / displ. | 36.07 % | ||
| Displ. / length | 115.06 | ||
| Comfort ratio | 13.92 | ||
| Capsize | 2.19 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.58 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 4840 lbs | ||
| Ballast | 1746 lbs | ||
| Hull speed | 6.91 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 420 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 166.16 sq.ft | ||
| Sail area main | 254.31 sq.ft | ||
| I | 32.17 ft | ||
| J | 10.33 ft | ||
| P | 36.33 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Murray Ross | ||
| First built | 1982 | ||
| Last built | 0 | ?? | |
| Number built | 65 |
